Key Features
Flexible,
Stable quality,
High productivity,
Less production cost,
Safer
Application:
1. Brass alloy products: faucet body, taps, valve, etc.
2. Zamak products: door handles, knobs, door lock plates etc.
3. Aluminum alloy products: furniture components, car wheels
4. Titanium alloy products: sports instruments like golf heads;
medical instruments
5. Stainless steel products: kitchenware and flatware, tableware,
stainless steel sinks, dishes, knives, and cutlery
6. Plastic parts: electroplated ABS like hand shower, automobile
components
7. Iron Castings: cabinets etc.
Only to make a few, for more application demands, please contact us
for a free consultation, we are always here to provide you the
turnkey polishing solutions.
Description
1. The automatic polishing machine is an exclusive polishing system
consisting of 4 manipulators with 6 Axis rotary systems;
Multiple stations' simultaneous operations ensure high flexibility
and high production efficiency.
2. The control system adopts PROMAX motion control technology from
Italy, with stable performance and high control accuracy.
3. Programming method: teaching programming, with the portable
handed device, contains manual mode to simulate the workmanship
polishing and record the track; automatically operating model is
available with pre-set parameters program.
4. Polishing pressure and wear compensation control performance:
When the polishing cloth wheel is worn out, the system can detect
that the torque has become smaller and automatically compensate in
all directions.
5. Linear speed compensation: When the outer diameter of the cloth
wheel is reduced, the system automatically increases the speed and
compensation;
6. Program setting of add polishing wax: free setting of wax
spraying time and frequency according to the characteristics of the
product. choice of a solid compound or liquid compound.
7. Fully digital control, it can store 50 programs. Programs can be
saved and recalled at any time.
8. CN/EN language display on Touch Panel. It is to set all
parameters for an easy operation; fault codes display and alarm
pages for quick troubleshooting and repair.
ADVANTAGES
-Uniform polishing quality without deformation of the processed
parts.
-High production. Four working stations work simultaneously, and
with one-time programming, the machine can finish the polishing and
buffing jobs of four workpieces at one time.
-Full auto, waxing system;
-Quick replacement of the fixtures.
-Quick replacement of the polishing mops.
-Cost reduction in the number of fixtures.
-Important reduction in mops and polishing compounds consumption.
-Polishing system avoiding excessive temperature of the parts
during the working process.
-Quick and easy programming. Interactive Teach System.
-Finish the polishing/buffing jobs in any angle and position;
-High profitability and amortization. One single operator can
handle several machines by synchronizing the working cycles.
Technical Specifications
| Code # | Item | Specifications |
| 1 | Model No. | RTAF-AP04 |
| 2 | Machine Layout (L*W*H)mm | 4400*3400*2800 |
| 3 | Power Consumption ( Max./Ave. ) KW | 40/25 |
| 4 | Working Power Environment | 3Ph, AC380V, 50Hz |
| 5 | Max. Polishing Mop Diameter (mm) | 600 |
| 6 | Min. Polishing Mop Diameter(mm) | 300 |
| 7 | X-Axis travel (mm) | 1100 |
| 8 | Y-Axis travel (mm) | 1000 |
| 9 | Z-Axis travel (mm) | 700 |
| 10 | U-Axis travel (mm) | ±90° |
| 11 | V-Axis travel (mm) | ±720° |
| 12 | W-Axis travel (mm) | ±720° |
| 13 | Program Recipes | Unlimited storage |
| 14 | Polishing Wax | Solid/Liquid for option |
| 15 | Max. speed of X-Axis | 20m/min. |
| 16 | Max. speed of Y-Axis | 20m/min. |
| 17 | Max. speed of Z-Axis | 20m/min. |
| 18 | Max. speed of U-Axis | 30°/sec. |
| 19 | Max. speed of V-Axis | 30°/sec. |
| 20 | Max. speed of W-Axis | 30°/sec. |
We provide you not only the polishing equipment but also know how
to transfer the technology, professional training, and technical
support for machine operation, and program writing. Please contact
us today for a FREE consultation.
