    2 Stations Rotary Polishing Machine, Automatic Polishing Machine With 2 Spindles, Automatic Polishing Machine

    Ask Lasest Price
    Brand Name : royal
    Model Number : RTAF-AP02
    Certification : ISO
    Price : negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 30 sets / month
    Delivery Time : 1 month
    • Product Details
    • Company Profile

    2 Stations Rotary Polishing Machine, Automatic Polishing Machine With 2 Spindles, Automatic Polishing Machine


    2 Stations Rotary Polishing Machine High Flexibility Automated Industrial Machinery


    Automatic polishing machines are born to replace heavy-labor workmanship and improve quality stability, reduce production costs, and for high yield benefits. Our machines have been offered worldwide in various industries:
    1. Faucets and sanitary fittings,
    2. Locks and door knobs, plates and door handles,
    3. Kitchenware and flatware, tableware, stainless steel sinks, dishes, Knives, and cutlery,
    4. Stainless steel round tubes, square bars, rectangular tubes, etc;
    5. Aluminum profiles;
    6. Automotive industry for wheels,
    7. Metal furniture parts;
    8. Valves and tools;
    9. Watch and jewelry;
    10. Medical implants;
    11. Musical instruments... more applications available are welcome to consult us.
    12. Max. product size: Φ 250*250mm;



    Key Features


    The automatic polishing machine is an exclusive polishing system consisting of 2 or 4 manipulators with 6 axises rotary; high flexibility and high product efficiency.
    Italy's PROMAX control system for high precision of control and high stability of movement technology.
    Software: Programmable, with portable handed device, contains manual mode to simulate the workmanship polishing and record the track; automatically operating model is available with pre-settled parameters program
    Polishing pressure and wear compensation control performance: When the polishing cloth wheel is worn out, the system can detect that the torque becomes smaller and automatically compensate in all directions.
    Linear speed compensation: When the outer diameter of the cloth wheel is reduced, the system automatically increases the speed and compensation;
    Solid polishing wax, to set up the wax spraying cycle time, and frequency.
    Full digital control, and polishing program parameters can be saved and adjusted at any time.
    CN/EN language display on Touch Panel. to set all parameters for easy operation; fault codes display and alarm pages for quick troubles shooting and repair

    Technical Parameters


    NO.DESCRIPTION2-STATIONS
    1Dimensions (L*W*H) MM3000*3100*3000
    2Power(KW)16.5
    3Voltage (v)380
    4Max. Diameter of polishing wheel (MM)600
    5Min. Diameter of polishing wheel400
    6X-axis Stroke1200
    7Y axis Stroke1100
    8Z axis Stroke700
    9U axis Stroke±90°
    10V axis Stroke±360°
    11W axis Stroke±360°

    Please consult us to improve your throughput and quality.
